How to Set Up OpenVPN with Docker: A Complete Guide

Running your own VPS server is definitely one of the best ways to secure your internet traffic, protect privacy, and access remote networks safely. OpenVPN is an open source VPN solution, and when combined with Docker, it becomes super easy to deploy, manage, and scale without dealing with additional complexity.

Instead of installing OpenVPN directly on your host system, you can always run it inside the Docker container to make it more portable, isolated, and quick for deployment. So if you want to set up a personal VPN for secure browsing or enable remote access, OpenVPN is a reliable solution.

In this guide, we shall discuss how to use OpenVPN with Docker, from prerequisites to a troubleshooting guide.

Why Run OpenVPN in Docker?

Running OpenVPN with Docker has multiple advantages, such as:

• It increases the portability between different environments and cloud providers.
• It keeps your VPN environment safe and separate from the host OS.
• Docker images like kylemanna/openvpn or linuxserver/openvpn-as provide ready-to-use setups.
• You can quickly spin up multiple instances if you need redundancy or load balancing.
• With Docker compose, you can easily manage the OpenVPN server with other services.
• No clutter of manually installed dependencies since everything is enclosed inside the container.

Prerequisites for OpenVPN on Docker

Before you start deploying OpenVPN on Docker, ensure that you have the following prerequisites ready to roll:

1. A Linux server or supported VPS like Ubuntu.
2. Install Docker and verify it by running docker –version.
3. Root or sudo privileges.
4. Firewall rules adjusted to allow VPN traffic.
5. Basic familiarity with Docker commands.

Deployment Options for OpenVPN in Docker

There are multiple different ways to deploy OpenVPN in Docker depending on your requirements.

1. Using Prebuilt Docker Images
   • Popular community images such as:
     • kylemanna/openvpn – lightweight, widely used.
     • linuxserver/openvpn-as – includes a web UI for easier management.
2. With Docker Compose

Docker Compose simplifies configuration and management of the OpenVPN container. It also allows integration with other services in a single YAML file.

3. Custom Dockerfile

If you need full control over the OpenVPN system, then you could build with a custom Dockerfile.

Step-by-Step Guide to Deploy OpenVPN in Docker

Step 1: Pull an OpenVPN Docker image

Run the following command to pull an OpenVPN Docker image:

docker pull kylemanna/openvpn

Step 2: Initialize the OpenVPN server configuration (and PKI)

• Now, create a directory on the host to store the OpenVPN configuration file by running: mkdir -p ~/openvpn-data
• Initialize the OpenVPN server configuration inside the container:

docker run -v ~/openvpn-data:/etc/openvpn –rm kylemanna/openvpn ovpn_genconfig -u udp://YOUR_SERVER_IP

Replace YOUR_SERVER_IP with your server’s public IP address or domain name.

• Next, initialize the public key infrastructure (PKI):

docker run -v ~/openvpn-data:/etc/openvpn –rm -it kylemanna/openvpn ovpn_initpki

Step 3: Start the OpenVPN server container

You can run the OpenVPN in the background, expose the port 1194/udp, and then allow networking capabilities.

docker run -d –name openvpn \

  -v ~/openvpn-data:/etc/openvpn \

  -p 1194:1194/udp \

  –cap-add=NET_ADMIN \

  –device /dev/net/tun \

  kylemanna/openvpn

• –cap-add=NET_ADMIN lets the container manage routes/iptables inside its namespace.
• –device /dev/net/tun ensures the TUN device is available (needed on many hosts).
• -p 1194:1194/udp publishes the VPN port to the host.

Verify it’s up:

docker logs -f openvpn

You should see OpenVPN listening on 0.0.0.0:1194 (or your chosen port/proto) with no errors.

Step 4: Expose and configure ports, routing, and firewall

Open the VPN port on the host firewall

• UFW:
  sudo ufw allow 1194/udp

sudo ufw status

• firewalld:
  sudo firewall-cmd –permanent –add-port=1194/udp

sudo firewall-cmd –reload

Enable IP forwarding on the host (so VPN clients can reach the internet/LAN)

sudo sysctl -w net.ipv4.ip_forward=1

echo ‘net.ipv4.ip_forward=1’ | sudo tee -a /etc/sysctl.conf

sudo sysctl -p

(If you’ll use IPv6, also set net.ipv6.conf.all.forwarding=1.)

DNS for clients (optional but recommended)

If your client wants to use specific DNS, add lines to the server config in the data folder.

push “redirect-gateway def1”

push “dhcp-option DNS 1.1.1.1”

push “dhcp-option DNS 9.9.9.9”

Then restart:

docker restart openvpn

Step 5: Generate and manage client profiles

Create client certs and export ready-to-use .ovpn files.

Create a client certificate (with or without password)

docker run –rm -it -v ~/openvpn-data:/etc/openvpn \

  kylemanna/openvpn easyrsa build-client-full alice nopass

docker run –rm -it -v ~/openvpn-data:/etc/openvpn \

  kylemanna/openvpn easyrsa build-client-full bob

Export the .ovpn profile

docker run –rm -v ~/openvpn-data:/etc/openvpn \

  kylemanna/openvpn ovpn_getclient alice > alice.ovpn

Send alice.ovpn to the user/device and import it into any OpenVPN client (Windows/macOS/Linux, iOS, Android).

Revoke a client (if lost/compromised)

docker run –rm -it -v ~/openvpn-data:/etc/openvpn \

  kylemanna/openvpn easyrsa revoke alice

docker run –rm -v ~/openvpn-data:/etc/openvpn \

  kylemanna/openvpn easyrsa gen-crl

docker restart openvpn

Smoke test

• Connect from a client with alice.ovpn.
• Visit https://ifconfig.io (or similar) to confirm your public IP is the server’s.
• If DNS doesn’t resolve, recheck the push “dhcp-option DNS …” lines.

Optional: run with Docker Compose

If you prefer Compose, create docker-compose.yml:

services:

  openvpn:

    image: kylemanna/openvpn

    container_name: openvpn

    restart: unless-stopped

    cap_add:

      – NET_ADMIN

    devices:

      – /dev/net/tun:/dev/net/tun

    ports:

      – “1194:1194/udp”

    volumes:

      – ./openvpn-data:/etc/openvpn

Then:

docker compose up -d

Configuring OpenVPN with Docker Compose

Using Docker Compose simplifies the management of OpenVPN containers by allowing you to define configurations in a docker-compose.yml file. Instead of running multiple docker run commands, you can declare the image, volumes, ports, and environment variables in one YAML configuration file. This makes it easy to scale, update, and redeploy the OpenVPN server with minimal effort.

Example docker-compose.yml:

version: ‘3.8’

services:

  openvpn:

    image: kylemanna/openvpn

    container_name: openvpn-server

    ports:

      – “1194:1194/udp”

    volumes:

      – ./openvpn-data/conf:/etc/openvpn

    cap_add:

      – NET_ADMIN

    restart: always

With this file in place, you can start the OpenVPN server using:

docker-compose up -d

Connecting Clients to Docker OpenVPN

Once the server is up and running, you need to generate client configuration files (.ovpn) that contain all the important certificates and connection details. These can be distributed among users who would connect to the VPN.

1. Generate client config
   docker run -v $(pwd)/openvpn-data/conf:/etc/openvpn –rm kylemanna/openvpn easyrsa build-client-full client1 nopass

docker run -v $(pwd)/openvpn-data/conf:/etc/openvpn –rm kylemanna/openvpn ovpn_getclient client1 > client1.ovpn

2. Transfer the .ovpn file to the client machine securely.
3. Use an OpenVPN client (available for Linux, macOS, Windows, Android, and iOS).
   openvpn –config client1.ovpn
4. Once connected, all traffic (or configured routes) will go through the VPN tunnel.

Managing and Monitoring OpenVPN Docker Containers

It is super important to manage and monitor OpenVPN Docker Containers regularly to keep them efficient and in top notch condition. Here are a few things to keep an eye on:

• Start/Stop containers:
  docker start openvpn-server

docker stop openvpn-server

• View logs:
  docker logs -f openvpn-server
• Update OpenVPN server image:
  docker-compose pull

docker-compose up -d

• Add or revoke users: Use the EasyRSA utilities inside the container to generate or revoke client certificates.

For automated monitoring, you can always integrate tools like Prometheus or Grafana.

Common Issues and Troubleshooting

Issue	Possible Cause	Solution
Clients can’t connect	Ports not exposed or firewall blocking	Ensure 1194/udp is open on the host and mapped in Docker
DNS not resolving inside VPN	Missing DNS config in .ovpn file	Add DNS servers (push “dhcp-option DNS 8.8.8.8”) to server config
Certificate errors	Misconfigured EasyRSA or expired certs	Re-generate certificates and ensure client uses the updated .ovpn file
Slow VPN speed	Limited CPU/memory resources or UDP blocked	Allocate more resources or switch to TCP port for OpenVPN
Container won’t start	Volume/permission issues	Verify volume mounts and permissions of openvpn-data/conf directory

Conclusion – Using OpenVPN Docker Containers

Running OpenVPN with Docker gives you the perfect balance between a lightweight, portable, and manageable VPN solution. You can employ the flexibility of a Docker container with the customization of an OpenVPN to securely manage servers!
